Vögele
AB 600

Vögele

AB 600

AB 600

Vögele extending screeds, with their outstanding adaptability, are ideal for paving in varying widths and on winding roads.

The AB 600 Extending Screed has a basic width of 3 m. Equipped with the VÖGELE single-tube telescoping system, its pave width is infinitely variable up to 6 m. With the addition of bolt-on extensions, even strips as wide as 9.5 m can be paved without joints. As a result, the AB 600 is ideally suited to combining with the VÖGELE pavers of the Universal Class and the Highway Class.

Highlights:

  • Ease of operation (Ergoplus command)
  • Standard or high compression
  • Great flexibility on site

Basic width
3,00 m

Hydraulically adjustable
3,00 - 6,00 m

Maximum pave width
9,50 m

Minimum pave width
3,00 m

Compaction group
V (vibration), T (tamper), P1 (one pressure bar) ou P2 (two pressure bares)

The extending screed with limitless applications

Offset Image
  • Single-tube telescoping system
  • Pave width infinitely variable up to 6 m
  • With the addition of bolt-on extensions, even strips as wide as 9.5 m can be paved without joints
  • Electric screed heating
  • Compacting systems with tamper and vibrators
  • High compaction system with pressure bars
